Dump Truck

Shacman F3000 8X4 6X4 12 Wheeler Dumper Used Euro 3 Euro 4 Dump Truck

The Shacman F3000 6*4 dump truck shines with its robust power. Its high - horsepower engines like WP10.340E22 offer strong torque for tough terrains. The durable chassis with MAN axles ensures stability. A large - capacity cargo box and fuel - efficient design make it a top choice for heavy - duty transportation tasks.

Vehicle Length: 8210mm - 8621mm
Vehicle Width: 2490mm - 2550mm
Vehicle Height: 3450mm
Rated Load Capacity: 12370kg - 12820kg
Wheelbase: 3575 + 1400mm - 3975 + 1400mm
Gross Vehicle Mass: 25000kg

Contact Now

Power System

• Engine: Models include WP10.340E22, WP12.430E20, etc., with corresponding horsepower of 340hp and 430hp respectively.

• Transmission: Model 10JSD180+QH50, with 10 forward gears and reverse gears.

• Clutch: Φ430 diaphragm spring clutch is mostly adopted.

Product detail diagram

010203040506

Chassis System

• Axles: The front axle is a MAN 9T axle, and the rear axle is a 16T MAN double-stage axle. The gear ratios include 5.92, 5.262, etc.

• Tires: Specification 12.00R20

• Suspension: Both front and rear suspensions are multi-leaf spring structures.

Advantages

01 /

Body and Cargo Box System

• Cab: F3000 medium-long flat-topped cab, equipped with air conditioning, hydraulic seat, manual window winder, etc.

• Cargo Box: Dimensions include 5.6×2.3×1.5m, 5.8×2.3×1.5m, etc. The plates are made of Q355 steel, and the thicknesses are such as 12mm for the bottom and 10mm for the sides, 8mm for the bottom and 6mm for the sides, etc.

02 /

Others

• Fuel Tank: Capacity 400L, made of aluminum alloy.

• Maximum Speed: 85km/h

Discover Sackman 6×4 dump truck F3000

01 /

Durability

Since its initial design, the F3000 has placed durability at the forefront. The sturdy high - strength alloy frame, combined with a reinforced suspension system, not only ensures the structural stability of the vehicle when fully loaded but also easily absorbs the impact from rough roads. This remarkable durability means lower maintenance costs and a longer service life, providing a solid guarantee for your investment.

Its high - power engine, with a power range from 371 to 420 horsepower, provides a continuous stream of power support for various transportation tasks. Paired with a carefully tuned 6×4 drive system, the F3000 can demonstrate excellent traction performance whether speeding on a flat highway or maneuvering through a muddy construction site, and easily handle all kinds of complex road conditions.

02 /

Unique Lightweight Design

The large - capacity dump body adopts a unique lightweight design, which effectively improves loading and unloading efficiency while ensuring load - bearing capacity. The tilt angle of the dump body has been optimized to ensure that materials can be quickly and completely unloaded, greatly saving operation time.

Inside the cab, the modern design style is perfectly integrated with ergonomics. The comfortable seats have multi - way adjustment functions to accommodate drivers of different builds; the simple and intuitive dashboard makes key information clear at a glance; the integrated control system is easy to operate, greatly reducing the driver's workload. In addition, the vehicle is equipped with a series of advanced safety configurations, such as Anti - lock Braking System (ABS) and Electronic Stability Control (ESC), comprehensively safeguarding driving safety.
